Energy Saving by Introducing High Efficiency Autoclave to Infusion Manufacturing Factory1

Representative Participant
Otsuka Pharmaceutical Factory, Inc.
Partner Participant: PT. Otsuka Indonesia
Host Country
Indonesia
Selected Year
2018
Type
JCM Model Project
Sector
Energy Efficiency
Not registered
Active

Outline of GHG Mitigation Activity

At an infusion manufacturing factory of PT. Otsuka Indonesia under the Otsuka Group, a new type of high efficiency autoclave, which fulfills the Good Manufacturing Practice (GMP) and realizes energy and resource saving, is introduced to contribute for CO2 emission as well as to assure safety of pharmaceutical products.
Since the hot water to be injected into the autoclave is maintained at a high temperature, both the amount of steam charged in a batch unit and consumption of natural gas (CNG) required for steam generation are reduced. In addition, the amount of pure water used in the sterilization process is also greatly reduced as it is reused without being discharged.

Expected GHG Emission Reductions

1,949 tCO2-eq./year

(Reference CNG consumption volume – project CNG consumption volume) X Emission factor of CNG.

  • CNG consumption volume = temp. rising cycle X theoretical required steam X coef. of theoretical required steam X coef. of CNG/steam.
  • temp. rising cycle = annual production volume / max volume of batch.
  • theoretical required steam = heat required for heating pure water at each cycle / evaporation latent heat.
  • coef. of theoretical required steam = steam generation volume in boiler / theoretical required steam.

coef. of CNG/steam = input volume of CNG / steam generation in bolier.

Site of JCM Project

JCM Methodology

Methodology No. Title Methodology Proponent
ID_AM028 Energy saving by introducing waste hot water recovery system to autoclave in infusion manufacturing process line Otsuka Pharmaceutical Factory, Inc.
